Pipe Fittings

Pipe is a round vessel for moving gas, liquid or steam. The size of a pipe is measured in Nominal Pipe Size (NPS) and wall thickness or Schedule. Main difference between a tube and a pipe is how they are measured. Tubes are measured by their precise OD, exactly matching the stated diameter within the tolerance. Pipes smaller than 14 inches Nominal Pipe Size actually have OD greater than 14 inches. At NPS 14 inches and larger, the OD matches the NPS. At any diameter, the Nominal Pipe Size does not change with wall thickness. Compared to tubes, pipes are typically used for longer runs, cannot be bent as easily as tubes and are stronger than tubes.

Swagelok Co.

NPT Nipple Pipe Fittings

Swagelok® close NPT nipples, without a hex between the two ends.
Nominal Pipe Size Material Mfg P/N Encole P/N Price
NPT 1/8” 316 SS SS-2-CN 1059E601 Contact Manufacturer
NPT 1/4” 316 SS SS-4-CN 1059E602 Contact Manufacturer
NPT 3/8” 316 SS SS-6-CN 1059E603 Contact Manufacturer
NPT 1/2” 316 SS SS-8-CN 1059E604 Contact Manufacturer
NPT 3/4” 316 SS SS-12-CN 1059E605 Contact Manufacturer
NPT 1” 316 SS SS-16-CN 1059E606 Contact Manufacturer

Swagelok Co.

NPT Hex Nipple Pipe Fittings

Swagelok® hex NPT nipples, with a hex for wrench placement between the two ends.
Nominal Pipe Size Material Mfg P/N Encole P/N Price
NPT 1/16” 316 SS SS-1-HN 1060E901 Contact Manufacturer
NPT 1/8” 316 SS SS-2-HN 1060E902 Contact Manufacturer
NPT 1/4” 316 SS SS-4-HN 1060E903 Contact Manufacturer
NPT 3/8” 316 SS SS-6-HN 1060E905 Contact Manufacturer
NPT 1/2” 316 SS SS-8-HN 1060E906 Contact Manufacturer
NPT 3/4” 316 SS SS-12-HN 1060E908 Contact Manufacturer
NPT 1” 316 SS SS-16-HN 1060E909 Contact Manufacturer

Swagelok Co.

BSPT (Tapered Thread) Hex Nipple Pipe Fittings

Swagelok® hex BSPT nipples, with a hex for wrench placement between the two ends. The thread complies with the British Whitworth Standard.
Nominal Pipe Size Material Mfg P/N Encole P/N Price
BSPT 1/8” 316 SS SS-2-HN-RT 1061E401 Contact Manufacturer
BSPT 1/4” 316 SS SS-4-HN-RT 1061E402 Contact Manufacturer
BSPT 3/8” 316 SS SS-6-HN-RT 1061E403 Contact Manufacturer
BSPT 1/2” 316 SS SS-8-HN-RT 1061E404 Contact Manufacturer

Swagelok Co.

NPT to BSPT (Tapered Thread) Hex Nipple Pipe Fittings

Swagelok® hex NPT to BSPT nipple adapters, with a hex for wrench placement between the two ends. The BSPT thread complies with the British Whitworth Standard.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
NPT 1/8” BSPT 1/8” 316 SS SS-2-HN-2RT 1062E601 Contact Manufacturer
NPT 1/4” BSPT 1/4” 316 SS SS-4-HN-4RT 1062E602 Contact Manufacturer
NPT 3/8” BSPT 3/8” 316 SS SS-6-HN-6RT 1062E603 Contact Manufacturer
NPT 1/2” BSPT 1/2” 316 SS SS-8-HN-8RT 1062E604 Contact Manufacturer
NPT 3/4” BSPT 3/4” 316 SS SS-12-HN-12RT 1062E605 Contact Manufacturer
NPT 1” BSPT 1” 316 SS SS-16-HN-16RT 1062E606 Contact Manufacturer

Swagelok Co.

NPT to BSPP (Parallel Thread) Hex Nipple Pipe Fittings

Swagelok® hex NPT to BSPP nipple adapters, with a hex for wrench placement between the two ends. The BSPP thread complies with the British Whitworth Standard.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
NPT 1/8” BSPP 1/8” 316 SS SS-2-HN-2RS 1063E601 Contact Manufacturer
NPT 1/4” BSPP 1/4” 316 SS SS-4-HN-4RS 1063E602 Contact Manufacturer
NPT 3/8” BSPP 3/8” 316 SS SS-6-HN-6RS 1063E603 Contact Manufacturer
NPT 1/2” BSPP 1/2” 316 SS SS-8-HN-8RS 1063E604 Contact Manufacturer
NPT 3/4” BSPP 3/4” 316 SS SS-12-HN-12RS 1063E605 Contact Manufacturer
NPT 1” BSPP 1” 316 SS SS-16-HN-16RS 1063E606 Contact Manufacturer

Swagelok Co.

Reducing Hex Nipple NPT Pipe Fittings

Swagelok® hex reducing nipples with two male NPT ends of different sizes. The fitting has a hex for wrench placement between the two ends.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
NPT 1/8” NPT 1/16” 316 SS SS-2-HRN-1 1064E1301 Contact Manufacturer
NPT 1/4” NPT 1/8” 316 SS SS-4-HRN-2 1064E1302 Contact Manufacturer
NPT 3/8” NPT 1/8” 316 SS SS-6-HRN-2 1064E1303 Contact Manufacturer
NPT 3/8” NPT 1/4” 316 SS SS-6-HRN-4 1064E1304 Contact Manufacturer
NPT 1/2” NPT 1/8” 316 SS SS-8-HRN-2 1064E1305 Contact Manufacturer
NPT 1/2” NPT 1/4” 316 SS SS-8-HRN-4 1064E1306 Contact Manufacturer
NPT 1/2” NPT 3/8” 316 SS SS-8-HRN-6 1064E1308 Contact Manufacturer
NPT 3/4” NPT 1/4” 316 SS SS-12-HRN-4 1064E1309 Contact Manufacturer
NPT 3/4” NPT 1/2” 316 SS SS-12-HRN-8 1064E13010 Contact Manufacturer
NPT 1” NPT 1/4” 316 SS SS-16-HRN-4 1064E13011 Contact Manufacturer
NPT 1” NPT 1/2” 316 SS SS-16-HRN-8 1064E13012 Contact Manufacturer
NPT 1” NPT 3/4” 316 SS SS-16-HRN-12 1064E13013 Contact Manufacturer

Swagelok Co.

Hex Long Nipple, NPT Pipe Fittings

Swagelok® hex long nipples with identical male NPT ends. These fittings are customizable to the desired length.
Nominal Pipe Size Material Mfg P/N Encole P/N Price
NPT 1/8” 316 SS SS-2-HLN-1.50 1065E2301 Contact Manufacturer
NPT 1/4” 316 SS SS-4-HLN-1.50 1065E2305 Contact Manufacturer
NPT 3/8” 316 SS SS-6-HLN-1.50 1065E23010 Contact Manufacturer
NPT 1/2” 316 SS SS-8-HLN-2.00 1065E23015 Contact Manufacturer
NPT 3/4” 316 SS SS-12-HLN-2.00 1065E23019 Contact Manufacturer
NPT 1” 316 SS SS-16-HLN-3.00 1065E23022 Contact Manufacturer

Swagelok Co.

Female to Male NPT Pipe Fitting Adapters

Swagelok® female NPT to male NPT pipe fitting adapters with two NPT ends of identical size, opposite gender. The fitting has a hex for wrench placement between the two ends.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
NPT 1/8” Female NPT 1/8” 316 SS SS-2-A 1066E801 Contact Manufacturer
NPT 1/4” Female NPT 1/4” 316 SS SS-4-A 1066E802 Contact Manufacturer
NPT 3/8” Female NPT 3/8” 316 SS SS-6-A 1066E804 Contact Manufacturer
NPT 1/2” Female NPT 1/2” 316 SS SS-8-A 1066E805 Contact Manufacturer
NPT 3/4” Female NPT 3/4” 316 SS SS-12-A 1066E807 Contact Manufacturer
NPT 1” Female NPT 1” 316 SS SS-16-A 1066E808 Contact Manufacturer

Swagelok Co.

Female to Male BSPT (Tapered Thread) Pipe Fitting Adapters

Swagelok® female to male pipe fitting adapters with two tapered thread BSPT ends of identical size, opposite gender. The threads conform to the British Whitworth Standard geometry.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
BSPT 1/8” Female BSPT 1/8” 316 SS SS-2-A-RT 1067E401 Contact Manufacturer
BSPT 1/4” Female BSPT 1/4” 316 SS SS-4-A-RT 1067E402 Contact Manufacturer
BSPT 3/8” Female BSPT 3/8” 316 SS SS-6-A-RT 1067E403 Contact Manufacturer
BSPT 1/2” Female BSPT 1/2” 316 SS SS-8-A-RT 1067E404 Contact Manufacturer

Swagelok Co.

Female NPT to Male BSPP (Parallel Thread) Pipe Fitting Adapters

Swagelok® female NPT to male ISO/BSPP (parallel thread) pipe fitting adapters. The ISO parallel thread conforms to the British Whitworth Standard geometry.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
Female NPT 1/8” BSPP 1/8” 316 SS SS-2-A-2-RS 1068E601 Contact Manufacturer
Female NPT 1/4” BSPP 1/4” 316 SS SS-4-A-4-RS 1068E602 Contact Manufacturer
Female NPT 3/8” BSPP 3/8” 316 SS SS-6-A-6-RS 1068E603 Contact Manufacturer
Female NPT 1/2” BSPP 1/2” 316 SS SS-8-A-8-RS 1068E604 Contact Manufacturer
Female NPT 3/4” BSPP 3/4” 316 SS SS-12-A-12-RS 1068E605 Contact Manufacturer
Female NPT 1” BSPP 1” 316 SS SS-16-A-16-RS 1068E606 Contact Manufacturer

Swagelok Co.

Female NPT to Male BSPT (Tapered Thread) Pipe Fitting Adapters

Swagelok® female NPT to male BSPT (tapered thread) pipe fitting adapters. The BSPT thread conforms to the British Whitworth Standard geometry.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
Female NPT 1/8” BSPT 1/8” 316 SS SS-2-A-2-RT 1069E601 Contact Manufacturer
Female NPT 1/4” BSPT 1/4” 316 SS SS-4-A-4-RT 1069E602 Contact Manufacturer
Female NPT 3/8” BSPT 3/8” 316 SS SS-6-A-6-RT 1069E603 Contact Manufacturer
Female NPT 1/2” BSPT 1/2” 316 SS SS-8-A-8-RT 1069E604 Contact Manufacturer
Female NPT 3/4” BSPT 3/4” 316 SS SS-12-A-12-RT 1069E605 Contact Manufacturer
Female NPT 1” BSPT 1” 316 SS SS-16-A-16-RT 1069E606 Contact Manufacturer

Swagelok Co.

NPT to Female BSPT (Tapered Thread) Pipe Fitting Adapters

Swagelok® male NPT to male ISO/BSPT (tapered thread) pipe fitting adapters. The ISO/BSPT tapered thread conforms to the British Whitworth Standard geometry.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
NPT 1/4” BSPT 1/4” 316 SS SS-4-AT-4 1070E601 Contact Manufacturer
NPT 3/8” BSPT 3/8” 316 SS SS-6-AT-6 1070E602 Contact Manufacturer
NPT 1/2” BSPT 1/2” 316 SS SS-8-AT-8 1070E603 Contact Manufacturer
NPT 1/4” BSPT 1/4” Brass B-4-AT-4 1070E604 Contact Manufacturer
NPT 3/8” BSPT 3/8” Brass B-6-AT-6 1070E605 Contact Manufacturer
NPT 1/2” BSPT 1/2” Brass B-8-AT-8 1070E606 Contact Manufacturer

Swagelok Co.

Male JIC (AN Flare) to NPT Pipe Fitting Adapters

Swagelok® male JIC (AN Flare) to male NPT pipe fitting adapters.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
AN-4, Tube Flare 1/4” NPT 1/4” 316 SS SS-4-AN-1-4 1071E601 Contact Manufacturer
AN-6, Tube Flare 3/8” NPT 1/4” 316 SS SS-6-AN-1-4 1071E602 Contact Manufacturer
AN-6, Tube Flare 3/8” NPT 3/8” 316 SS SS-6-AN-1-6 1071E603 Contact Manufacturer
AN-8, Tube Flare 1/2” NPT 1/2” 316 SS SS-8-AN-1-8 1071E604 Contact Manufacturer
AN-12, Tube Flare 3/4” NPT 3/4” 316 SS SS-12-AN-1-12 1071E605 Contact Manufacturer
AN-16, Tube Flare 1” NPT 1” 316 SS SS-16-AN-1-16 1071E606 Contact Manufacturer

Swagelok Co.

Male SAE J514 to Female NPT Pipe Fitting Adapters

Swagelok® SAE to female NPT pipe fitting adapters. The SAE end conforms to the SAE J514 geometry designed to fit into J1926/1 port.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
SAE-4 Female NPT 1/4” 316 SS SS-4-SAE-7-4 1072E501 Contact Manufacturer
SAE-6 Female NPT 3/8” 316 SS SS-6-SAE-7-6 1072E502 Contact Manufacturer
SAE-8 Female NPT 1/2” 316 SS SS-8-SAE-7-8 1072E503 Contact Manufacturer
SAE-12 Female NPT 3/4” 316 SS SS-12-SAE-7-12 1072E504 Contact Manufacturer
SAE-16 Female NPT 1” 316 SS SS-16-SAE-7-16 1072E505 Contact Manufacturer

Swagelok Co.

SAE J514 to JIC (AN Flare) Pipe Fitting Adapters

Swagelok® SAE to AN flare pipe fitting adapters. The SAE end conforms to the SAE J514 geometry designed to fit into J1926/1 port.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
SAE-4 AN-4, Tube Flare 1/4” 316 SS SS-4-SAE-1-4AN 1073E501 Contact Manufacturer
SAE-6 AN-6, Tube Flare 3/8” 316 SS SS-6-SAE-1-6AN 1073E502 Contact Manufacturer
SAE-8 AN-8, Tube Flare 1/2” 316 SS SS-8-SAE-1-8AN 1073E503 Contact Manufacturer
SAE-12 AN-12, Tube Flare 3/4” 316 SS SS-12-SAE-1-12AN 1073E504 Contact Manufacturer
SAE-16 AN-16, Tube Flare 1” 316 SS SS-16-SAE-1-16AN 1073E505 Contact Manufacturer

Swagelok Co.

NPT to SAE J514 Pipe Fitting Adapters

Swagelok® male NPT to SAE pipe fitting adapters. The SAE end conforms to the SAE J514 geometry designed to fit into J1926/1 port.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
SAE-4 NPT 1/4” 316 SS SS-4-SAE-1-4 1074E501 Contact Manufacturer
SAE-6 NPT 3/8” 316 SS SS-6-SAE-1-6 1074E502 Contact Manufacturer
SAE-8 NPT 1/2” 316 SS SS-8-SAE-1-8 1074E503 Contact Manufacturer
SAE-12 NPT 3/4” 316 SS SS-12-SAE-1-12 1074E504 Contact Manufacturer
SAE-16 NPT 1” 316 SS SS-16-SAE-1-16 1074E505 Contact Manufacturer

Swagelok Co.

Female NPT to Male NPT Pipe Fitting Reducing Adapters

Swagelok® female NPT to male NPT pipe fitting reducers. The female thread is larger than the male thread.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
Female NPT 1/8” NPT 1/16” 316 SS SS-2-RA-1 1075E1401 Contact Manufacturer
Female NPT 1/4” NPT 1/8” 316 SS SS-4-RA-2 1075E1402 Contact Manufacturer
Female NPT 3/8” NPT 1/8” 316 SS SS-6-RA-2 1075E1403 Contact Manufacturer
Female NPT 3/8” NPT 1/4” 316 SS SS-6-RA-4 1075E1404 Contact Manufacturer
Female NPT 1/2” NPT 1/8” 316 SS SS-8-RA-2 1075E1405 Contact Manufacturer
Female NPT 1/2” NPT 1/4” 316 SS SS-8-RA-4 1075E1406 Contact Manufacturer
Female NPT 1/2” NPT 3/8” 316 SS SS-8-RA-6 1075E1408 Contact Manufacturer
Female NPT 3/4” NPT 1/4” 316 SS SS-12-RA-4 1075E1409 Contact Manufacturer
Female NPT 3/4” NPT 3/8” 316 SS SS-12-RA-6 1075E14010 Contact Manufacturer
Female NPT 3/4” NPT 1/2” 316 SS SS-12-RA-8 1075E14011 Contact Manufacturer
Female NPT 1” NPT 1/4” 316 SS SS-16-RA-4 1075E14012 Contact Manufacturer
Female NPT 1” NPT 1/2” 316 SS SS-16-RA-8 1075E14013 Contact Manufacturer
Female NPT 1” NPT 3/4” 316 SS SS-16-RA-12 1075E14014 Contact Manufacturer

Swagelok Co.

Female BSPT (Tapered Thread) to Male BSPT Pipe Fitting Reducing Adapters

Swagelok® female BSPT to male BSPT pipe fitting reducers. The female thread is larger than the male thread. Threads conform to the British Whitworth Standard.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
Female BSPT 1/4” BSPT 1/8” 316 SS SS-4-RAT-2RT 1076E401 Contact Manufacturer
Female BSPT 3/8” BSPT 1/8” 316 SS SS-6-RAT-2RT 1076E402 Contact Manufacturer
Female BSPT 1/2” BSPT 1/4” 316 SS SS-8-RAT-4RT 1076E403 Contact Manufacturer
Female BSPT 1/2” BSPT 3/8” 316 SS SS-8-RAT-6RT 1076E404 Contact Manufacturer

Swagelok Co.

Male NPT to Female NPT Pipe Fitting Reducing Bushings

Swagelok® male NPT to female NPT pipe fitting bushings. The male thread is larger than the female thread.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
NPT 1/8” Female NPT 1/16” 316 SS SS-2-RB-1 1077E1401 Contact Manufacturer
NPT 1/4” Female NPT 1/8” 316 SS SS-4-RB-2 1077E1402 Contact Manufacturer
NPT 3/8” Female NPT 1/8” 316 SS SS-6-RB-2 1077E1403 Contact Manufacturer
NPT 3/8” Female NPT 1/4” 316 SS SS-6-RB-4 1077E1404 Contact Manufacturer
NPT 1/2” Female NPT 1/8” 316 SS SS-8-RB-2 1077E1405 Contact Manufacturer
NPT 1/2” Female NPT 1/4” 316 SS SS-8-RB-4 1077E1406 Contact Manufacturer
NPT 1/2” Female NPT 3/8” 316 SS SS-8-RB-6 1077E1407 Contact Manufacturer
NPT 3/4” Female NPT 1/4” 316 SS SS-12-RB-4 1077E1408 Contact Manufacturer
NPT 3/4” Female NPT 3/8” 316 SS SS-12-RB-6 1077E1409 Contact Manufacturer
NPT 3/4” Female NPT 1/2” 316 SS SS-12-RB-8 1077E14010 Contact Manufacturer
NPT 1” Female NPT 1/4” 316 SS SS-16-RB-4 1077E14011 Contact Manufacturer
NPT 1” Female NPT 3/8” 316 SS SS-16-RB-6 1077E14012 Contact Manufacturer
NPT 1” Female NPT 1/2” 316 SS SS-16-RB-8 1077E14013 Contact Manufacturer
NPT 1” Female NPT 3/4” 316 SS SS-16-RB-12 1077E14014 Contact Manufacturer

Swagelok Co.

Male BSPT (Tapered Thread) to Female BSPT Pipe Fitting Reducing Bushings

Swagelok® male BSPT to female BSPT pipe fitting bushings. The male thread is larger than the female thread. Threads comply with the British Whitworth Standard.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
BSPT 1/4” Female BSPT 1/8” 316 SS SS-4-RBT-2RT 1078E401 Contact Manufacturer
BSPT 3/8” Female BSPT 1/4” 316 SS SS-6-RBT-4RT 1078E402 Contact Manufacturer
BSPT 1/2” Female BSPT 1/4” 316 SS SS-8-RBT-4RT 1078E403 Contact Manufacturer
BSPT 1/2” Female BSPT 3/8” 316 SS SS-8-RBT-6RT 1078E404 Contact Manufacturer

Swagelok Co.

Male to Female SAE Pipe Fitting Bushings

Swagelok® male SAE to female SAE port pipe fitting bushings. The male thread is larger than the female thread. SAE connections comply with SAEJ514 Standard geometry.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
SAE-6 Female SAE-4 Port 316 SS SS-6-RBST-4 1079E901 Contact Manufacturer
SAE-8 Female SAE-4 Port 316 SS SS-8-RBST-4 1079E902 Contact Manufacturer
SAE-8 Female SAE-6 Port 316 SS SS-8-RBST-6 1079E903 Contact Manufacturer
SAE-10 Female SAE-6 Port 316 SS SS-10-RBST-6 1079E904 Contact Manufacturer
SAE-10 Female SAE-8 Port 316 SS SS-10-RBST-8 1079E905 Contact Manufacturer
SAE-12 Female SAE-8 Port 316 SS SS-12-RBST-8 1079E906 Contact Manufacturer
SAE-16 Female SAE-12 Port 316 SS SS-16-RBST-12 1079E907 Contact Manufacturer
SAE-20 Female SAE-16 Port 316 SS SS-20-RBST-16 1079E908 Contact Manufacturer
SAE-24 Female SAE-16 Port 316 SS SS-24-RBST-16 1079E909 Contact Manufacturer

Swagelok Co.

NPT Female Coupling Pipe Fittings

Swagelok® hex couplings with identical female NPT ends.
Nominal Pipe Size Material Mfg P/N Encole P/N Price
NPT 1/8” 316 SS SS-2-HCG 1080E801 Contact Manufacturer
NPT 1/4” 316 SS SS-4-HCG 1080E802 Contact Manufacturer
NPT 3/8” 316 SS SS-6-HCG 1080E804 Contact Manufacturer
NPT 1/2” 316 SS SS-8-HCG 1080E805 Contact Manufacturer
NPT 3/4” 316 SS SS-12-HCG 1080E807 Contact Manufacturer
NPT 1” 316 SS SS-16-HCG 1080E808 Contact Manufacturer

Swagelok Co.

BSPT (Tapered Thread) Coupling Pipe Fittings

Swagelok® hex couplings with identical female BSPT ends. The threads comply with the British Whitworth Standard.
Nominal Pipe Size Material Mfg P/N Encole P/N Price
BSPT 1/8” 316 SS SS-2-HCG-RT 1081E401 Contact Manufacturer
BSPT 1/4” 316 SS SS-4-HCG-RT 1081E402 Contact Manufacturer
BSPT 3/8” 316 SS SS-6-HCG-RT 1081E403 Contact Manufacturer
BSPT 1/2” 316 SS SS-8-HCG-RT 1081E404 Contact Manufacturer

Swagelok Co.

Female NPT Reducing Coupling Pipe Fittings

Swagelok® reducing couplings with female NPT ends of different size.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
NPT 1/4” Female NPT 1/8” 316 SS SS-4-HRCG-2 1082E1001 Contact Manufacturer
NPT 3/8” Female NPT 1/4” 316 SS SS-6-HRCG-4 1082E1002 Contact Manufacturer
NPT 1/2” Female NPT 1/8” 316 SS SS-8-HRCG-2 1082E1003 Contact Manufacturer
NPT 1/2” Female NPT 1/4” 316 SS SS-8-HRCG-4 1082E1004 Contact Manufacturer
NPT 1/2” Female NPT 3/8” 316 SS SS-8-HRCG-6 1082E1006 Contact Manufacturer
NPT 3/4” Female NPT 1/4” 316 SS SS-12-HRCG-4 1082E1007 Contact Manufacturer
NPT 3/4” Female NPT 1/2” 316 SS SS-12-HRCG-8 1082E1008 Contact Manufacturer
NPT 1” Female NPT 1/2” 316 SS SS-16-HRCG-8 1082E1009 Contact Manufacturer
NPT 1” Female NPT 3/4” 316 SS SS-16-HRCG-12 1082E10010 Contact Manufacturer

Swagelok Co.

BSPT (Tapered Thread) Reducing Coupling Pipe Fittings

Swagelok® hex reducers with female BSPT ends of different sizes. The threads comply with the British Whitworth Standard.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
BSPT 3/8” Female BSPT 1/4” 316 SS SS-6-HRCGT-4RT 1083E301 Contact Manufacturer
BSPT 1/2” Female BSPT 1/4” 316 SS SS-8-HRCGT-4RT 1083E302 Contact Manufacturer
BSPT 1/2” Female BSPT 3/8” 316 SS SS-8-HRCGT-6RT 1083E303 Contact Manufacturer

Swagelok Co.

Female NPT Pipe Fitting Elbows

Swagelok® pipe fitting elbows with identical female NPT ends.
Nominal Pipe Size Material Mfg P/N Encole P/N Price
NPT 1/8” 316 SS SS-2-E 1084E801 Contact Manufacturer
NPT 1/4” 316 SS SS-4-E 1084E802 Contact Manufacturer
NPT 3/8” 316 SS SS-6-E 1084E804 Contact Manufacturer
NPT 1/2” 316 SS SS-8-E 1084E805 Contact Manufacturer
NPT 3/4” 316 SS SS-12-E 1084E807 Contact Manufacturer
NPT 1” 316 SS SS-16-E 1084E808 Contact Manufacturer

Swagelok Co.

Female BSPT (Tapered Thread) Pipe Fitting Elbows

Swagelok® pipe fitting 90-degree elbows with identical female BSPT ends. The threads comply with the British Whitworth Standard.
Nominal Pipe Size Material Mfg P/N Encole P/N Price
BSPT 1/4” 316 SS SS-4-E-RT 1085E301 Contact Manufacturer
BSPT 3/8” 316 SS SS-6-E-RT 1085E302 Contact Manufacturer
BSPT 1/2” 316 SS SS-8-E-RT 1085E303 Contact Manufacturer

Swagelok Co.

NPT Pipe Fitting 90-Degree Elbows

Swagelok® pipe fitting elbows with identical male NPT ends.
Nominal Pipe Size Material Mfg P/N Encole P/N Price
NPT 1/8” 316 SS SS-2-ME 1086E401 Contact Manufacturer
NPT 1/4” 316 SS SS-4-ME 1086E402 Contact Manufacturer
NPT 3/8” 316 SS SS-6-ME 1086E403 Contact Manufacturer
NPT 1/2” 316 SS SS-8-ME 1086E404 Contact Manufacturer

Swagelok Co.

NPT Pipe Fitting Street Elbows

Swagelok® pipe fitting elbows with a female to male NPT ends.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
NPT 1/16” Female NPT 1/16” 316 SS SS-1-SE 1087E701 Contact Manufacturer
NPT 1/8” Female NPT 1/8” 316 SS SS-2-SE 1087E702 Contact Manufacturer
NPT 1/4” Female NPT 1/4” 316 SS SS-4-SE 1087E703 Contact Manufacturer
NPT 3/8” Female NPT 3/8” 316 SS SS-6-SE 1087E704 Contact Manufacturer
NPT 1/2” Female NPT 1/2” 316 SS SS-8-SE 1087E705 Contact Manufacturer
NPT 3/4” Female NPT 3/4” 316 SS SS-12-SE 1087E706 Contact Manufacturer
NPT 1” Female NPT 1” 316 SS SS-16-SE 1087E707 Contact Manufacturer

Swagelok Co.

NPT Reducing Street Elbow Pipe Fittings

Swagelok® pipe fitting reducing elbows with a female to male NPT ends of different sizes.
Nominal Pipe Size Connection 2 Material Mfg P/N Encole P/N Price
NPT 1/8” Female NPT 1/16” 316 SS SS-2-RSE-1 1088E401 Contact Manufacturer
NPT 1/4” Female NPT 1/8” 316 SS SS-4-RSE-2 1088E402 Contact Manufacturer
NPT 3/8” Female NPT 1/4” 316 SS SS-6-RSE-4 1088E403 Contact Manufacturer
NPT 1/2” Female NPT 1/4” 316 SS SS-8-RSE-4 1088E404 Contact Manufacturer

Swagelok Co.

Female NPT Pipe Fitting Tees

pipe-fitting-tee-female-npt-group 1.png
Swagelok® pipe fitting tees with female NPT ends of identical sizes.
Nominal Pipe Size Material Mfg P/N Encole P/N Price
NPT 1/8” 316 SS SS-2-T 1089E801 Contact Manufacturer
NPT 1/4” 316 SS SS-4-T 1089E802 Contact Manufacturer
NPT 3/8” 316 SS SS-6-T 1089E804 Contact Manufacturer
NPT 1/2” 316 SS SS-8-T 1089E805 Contact Manufacturer
NPT 3/4” 316 SS SS-12-T 1089E807 Contact Manufacturer
NPT 1” 316 SS SS-16-T 1089E808 Contact Manufacturer

Swagelok Co.

Female BSPT (Tapered Thread) Pipe Fitting Tees

pipe-fitting-tee-female-bspt-group 1.png
Swagelok® pipe fitting tees with female BSPT ends of identical sizes. The thread geometry complies with the British Whitworth Standard.
Nominal Pipe Size Material Mfg P/N Encole P/N Price
BSPT 1/4” 316 SS SS-4-T-RT 1090E301 Contact Manufacturer
BSPT 3/8” 316 SS SS-6-T-RT 1090E302 Contact Manufacturer
BSPT 1/2” 316 SS SS-8-T-RT 1090E303 Contact Manufacturer

Swagelok Co.

Male NPT Pipe Fitting Tees

Swagelok® pipe fitting tees with male NPT ends of identical sizes.
Nominal Pipe Size Material Mfg P/N Encole P/N Price
NPT 1/8” 316 SS SS-2-MT 1091E401 Contact Manufacturer
NPT 1/4” 316 SS SS-4-MT 1091E402 Contact Manufacturer
NPT 3/8” 316 SS SS-6-MT 1091E403 Contact Manufacturer
NPT 1/2” 316 SS SS-8-MT 1091E404 Contact Manufacturer

Swagelok Co.

Branch Male and Run Female NPT Pipe Fitting Tees

Swagelok® pipe fitting tees with two identical female NPT ends on the run (in-line of the tee) and a male NPT end on the branch (perpendicular to the run).
Nominal Pipe Size Material Mfg P/N Encole P/N Price
NPT 1/8” 316 SS SS-2-BT 1092E401 Contact Manufacturer
NPT 1/4” 316 SS SS-4-BT 1092E402 Contact Manufacturer
NPT 3/8” 316 SS SS-6-BT 1092E403 Contact Manufacturer
NPT 1/2” 316 SS SS-8-BT 1092E404 Contact Manufacturer

Swagelok Co.

Run Male and Branch Female NPT Street Tees

Swagelok® pipe fitting tees with a female to male NPT ends on the run (in-line of the tee) and a female NPT end on the branch (perpendicular to the run).
Nominal Pipe Size Material Mfg P/N Encole P/N Price
NPT 1/8” 316 SS SS-2-ST 1093E501 Contact Manufacturer
NPT 1/4” 316 SS SS-4-ST 1093E502 Contact Manufacturer
NPT 3/8” 316 SS SS-6-ST 1093E503 Contact Manufacturer
NPT 1/2” 316 SS SS-8-ST 1093E504 Contact Manufacturer
NPT 3/4” 316 SS SS-12-ST 1093E505 Contact Manufacturer

Swagelok Co.

Female NPT Pipe Fitting Crosses

Swagelok® pipe fitting crosses with identical female NPT ends.
Nominal Pipe Size Material Mfg P/N Encole P/N Price
NPT 1/8” 316 SS SS-2-CS 1094E601 Contact Manufacturer
NPT 1/4” 316 SS SS-4-CS 1094E602 Contact Manufacturer
NPT 3/8” 316 SS SS-6-CS 1094E603 Contact Manufacturer
NPT 1/2” 316 SS SS-8-CS 1094E604 Contact Manufacturer
NPT 3/4” 316 SS SS-12-CS 1094E605 Contact Manufacturer
NPT 1” 316 SS SS-16-CS 1094E606 Contact Manufacturer

Loading...
