Tube Fittings

Tube Fittings

Tube fittings with compression ferrules. Metal-to-metal grip offers a direct to the tube clean seal without use of elastomers. Compression tube fittings withstand vibration, repeated thermal expansion and pressure cycles. The advantage of this design is excellent vibration fatigue resistance, no torque transmitted to tubing during installation, and consistent remakes. Typical uses for swaged tube connections is in applications requiring no outgassing from elastomer seals and frequent disassembles of plumbing lines. The difference between Tube and Pipe fittings is tube fittings are measured as Tube Outer Diameter, while pipe fittings are measured in Nominal Pipe Size (NPS). Typically tube fittings have tight tolerance of their specified outer diameter.

Swagelok Co.

Straight Union Tube Fittings, Standard Inch Size

Swagelok compression tube fitting unions, where both ends are identical. Fractional sizes.
Tube OD Material Mfg P/N Encole P/N Price
1/16” 316 SS SS-100-6 909E1601 Contact Manufacturer
1/8” 316 SS SS-200-6 909E1602 Contact Manufacturer
3/16” 316 SS SS-300-6 909E1603 Contact Manufacturer
1/4” 316 SS SS-400-6 909E1604 Contact Manufacturer
5/16” 316 SS SS-500-6 909E1605 Contact Manufacturer
3/8” 316 SS SS-600-6 909E1606 Contact Manufacturer
1/2” 316 SS SS-810-6 909E1607 Contact Manufacturer
5/8” 316 SS SS-1010-6 909E1609 Contact Manufacturer
3/4” 316 SS SS-1210-6 909E16010 Contact Manufacturer
7/8” 316 SS SS-1410-6 909E16011 Contact Manufacturer
1” 316 SS SS-1610-6 909E16012 Contact Manufacturer
1-1/8” 316 SS SS-1810-6 909E16013 Contact Manufacturer
1-1/4” 316 SS SS-2000-6 909E16014 Contact Manufacturer
1-1/2” 316 SS SS-2400-6 909E16015 Contact Manufacturer
2” 316 SS SS-3200-6 909E16016 Contact Manufacturer

Swagelok Co.

Straight Union Tube Fitting, Metric Size

Compression tube fittings with identical metric size connections on both ends.
Tube OD Material Mfg P/N Encole P/N Price
2 mm 316 SS SS-2M0-6 910E2201 Contact Manufacturer
3 mm 316 SS SS-3M0-6 910E2202 Contact Manufacturer
4 mm 316 SS SS-4M0-6 910E2203 Contact Manufacturer
6 mm 316 SS SS-6M0-6 910E2204 Contact Manufacturer
8 mm 316 SS SS-8M0-6 910E2205 Contact Manufacturer
10 mm 316 SS SS-10M0-6 910E2206 Contact Manufacturer
12 mm 316 SS SS-12M0-6 910E2207 Contact Manufacturer
14 mm 316 SS SS-14M0-6 910E2208 Contact Manufacturer
15 mm 316 SS SS-15M0-6 910E2209 Contact Manufacturer
16 mm 316 SS SS-16M0-6 910E22010 Contact Manufacturer
18 mm 316 SS SS-18M0-6 910E22011 Contact Manufacturer
20 mm 316 SS SS-20M0-6 910E22012 Contact Manufacturer
22 mm 316 SS SS-22M0-6 910E22013 Contact Manufacturer
25 mm 316 SS SS-25M0-6 910E22014 Contact Manufacturer
28 mm 316 SS SS-28M0-6 910E22015 Contact Manufacturer
28 mm Brass B-28M0-6 910E22017 Contact Manufacturer
30 mm 316 SS SS-30M0-6 910E22019 Contact Manufacturer
32 mm 316 SS SS-32M0-6 910E22020 Contact Manufacturer
38 mm 316 SS SS-38M0-6 910E22021 Contact Manufacturer
50 mm 316 SS SS-50M0-6 910E22022 Contact Manufacturer

Swagelok Co.

Straight Union Tube Fittings, Metric to Fractional Size

Tube fitting unions with metric size on one end, and fractional inch size on the other end of the fitting.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
2 mm 1/8” 316 SS SS-2M0-6-2 911E2601 Contact Manufacturer
2 mm 1/4” 316 SS SS-2M0-6-4 911E2602 Contact Manufacturer
3 mm 1/8” 316 SS SS-3M0-6-2 911E2603 Contact Manufacturer
4 mm 1/8” 316 SS SS-4M0-6-2 911E2604 Contact Manufacturer
4 mm 1/4” 316 SS SS-4M0-6-4 911E2605 Contact Manufacturer
6 mm 1/16” 316 SS SS-6M0-6-1 911E2606 Contact Manufacturer
6 mm 1/8” 316 SS SS-6M0-6-2 911E2607 Contact Manufacturer
6 mm 1/4” 316 SS SS-6M0-6-4 911E2608 Contact Manufacturer
6 mm 5/16” 316 SS SS-6M0-6-5 911E2609 Contact Manufacturer
6 mm 3/8” 316 SS SS-6M0-6-6 911E26010 Contact Manufacturer
8 mm 1/4” 316 SS SS-8M0-6-4 911E26011 Contact Manufacturer
8 mm 3/8” 316 SS SS-8M0-6-6 911E26012 Contact Manufacturer
10 mm 1/8” 316 SS SS-10M0-6-2 911E26013 Contact Manufacturer
10 mm 1/4” 316 SS SS-10M0-6-4 911E26014 Contact Manufacturer
10 mm 5/16” 316 SS SS-10M0-6-5 911E26015 Contact Manufacturer
10 mm 3/8” 316 SS SS-10M0-6-6 911E26016 Contact Manufacturer
12 mm 1/4” 316 SS SS-12M0-6-4 911E26017 Contact Manufacturer
12 mm 5/16” 316 SS SS-12M0-6-5 911E26018 Contact Manufacturer
12 mm 3/8” 316 SS SS-12M0-6-6 911E26019 Contact Manufacturer
12 mm 1/2” 316 SS SS-12M0-6-8 911E26020 Contact Manufacturer
15 mm 1/2” 316 SS SS-15M0-6-8 911E26021 Contact Manufacturer
16 mm 5/8” 316 SS SS-16M0-6-10 911E26022 Contact Manufacturer
18 mm 3/4” 316 SS SS-18M0-6-12 911E26023 Contact Manufacturer
20 mm 1/2” 316 SS SS-20M0-6-8 911E26024 Contact Manufacturer
20 mm 1” 316 SS SS-20M0-6-16 911E26025 Contact Manufacturer
25 mm 1” 316 SS SS-25M0-6-16 911E26026 Contact Manufacturer

Swagelok Co.

Straight Reducing Union Tube Fittings, Fractional Size

Compression type tube fittings with different fractional sizes on the ends.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
1/8” 1/16” 316 SS SS-200-6-1 912E2301 Contact Manufacturer
3/16” 1/16” 316 SS SS-300-6-1 912E2302 Contact Manufacturer
3/16” 1/8” 316 SS SS-300-6-2 912E2303 Contact Manufacturer
1/4” 1/16” 316 SS SS-400-6-1 912E2304 Contact Manufacturer
1/4” 1/8” 316 SS SS-400-6-2 912E2305 Contact Manufacturer
1/4” 3/16” 316 SS SS-400-6-3 912E2306 Contact Manufacturer
5/16” 1/8” 316 SS SS-500-6-2 912E2307 Contact Manufacturer
5/16” 1/4” 316 SS SS-500-6-4 912E2308 Contact Manufacturer
3/8” 1/16” 316 SS SS-600-6-1 912E2309 Contact Manufacturer
3/8” 1/8” 316 SS SS-600-6-2 912E23010 Contact Manufacturer
3/8” 1/4” 316 SS SS-600-6-4 912E23011 Contact Manufacturer
3/8” 5/16” 316 SS SS-600-6-5 912E23012 Contact Manufacturer
1/2” 1/8” 316 SS SS-810-6-2 912E23013 Contact Manufacturer
1/2” 1/4” 316 SS SS-810-6-4 912E23014 Contact Manufacturer
1/2” 3/8” 316 SS SS-810-6-6 912E23015 Contact Manufacturer
5/8” 3/8” 316 SS SS-1010-6-6 912E23016 Contact Manufacturer
5/8” 1/2” 316 SS SS-1010-6-8 912E23017 Contact Manufacturer
3/4” 1/4” 316 SS SS-1210-6-4 912E23018 Contact Manufacturer
3/4” 3/8” 316 SS SS-1210-6-6 912E23019 Contact Manufacturer
3/4” 1/2” 316 SS SS-1210-6-8 912E23020 Contact Manufacturer
3/4” 5/8” 316 SS SS-1210-6-10 912E23021 Contact Manufacturer
1” 1/2” 316 SS SS-1610-6-8 912E23022 Contact Manufacturer
1” 3/4” 316 SS SS-1610-6-12 912E23023 Contact Manufacturer

Swagelok Co.

Straight Reducing Union Tube Fittings, Metric

Compression type tube fittings with different metric sizes on the ends.Compression type tube fittings with different metric sizes on the ends.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
3 mm 2 mm 316 SS SS-3M0-6-2M 913E2401 Contact Manufacturer
6 mm 2 mm 316 SS SS-6M0-6-2M 913E2402 Contact Manufacturer
6 mm 3 mm 316 SS SS-6M0-6-3M 913E2403 Contact Manufacturer
6 mm 4 mm 316 SS SS-6M0-6-4M 913E2404 Contact Manufacturer
8 mm 6 mm 316 SS SS-8M0-6-6M 913E2405 Contact Manufacturer
10 mm 6 mm 316 SS SS-10M0-6-6M 913E2406 Contact Manufacturer
10 mm 8 mm 316 SS SS-10M0-6-8M 913E2407 Contact Manufacturer
12 mm 6 mm 316 SS SS-12M0-6-6M 913E2408 Contact Manufacturer
12 mm 8 mm 316 SS SS-12M0-6-8M 913E2409 Contact Manufacturer
12 mm 10 mm 316 SS SS-12M0-6-10M 913E24010 Contact Manufacturer
16 mm 10 mm 316 SS SS-16M0-6-10M 913E24011 Contact Manufacturer
16 mm 12 mm 316 SS SS-16M0-6-12M 913E24012 Contact Manufacturer
18 mm 12 mm 316 SS SS-18M0-6-12M 913E24013 Contact Manufacturer
25 mm 18 mm 316 SS SS-25M0-6-18M 913E24014 Contact Manufacturer
25 mm 20 mm 316 SS SS-25M0-6-20M 913E24015 Contact Manufacturer
30 mm 18 mm 316 SS SS-30M0-6-18M 913E24016 Contact Manufacturer
30 mm 20 mm 316 SS SS-30M0-6-20M 913E24017 Contact Manufacturer
30 mm 25 mm 316 SS SS-30M0-6-25M 913E24018 Contact Manufacturer
32 mm 18 mm 316 SS SS-32M0-6-18M 913E24019 Contact Manufacturer
32 mm 20 mm 316 SS SS-32M0-6-20M 913E24020 Contact Manufacturer
32 mm 25 mm 316 SS SS-32M0-6-25M 913E24021 Contact Manufacturer
38 mm 20 mm 316 SS SS-38M0-6-20M 913E24022 Contact Manufacturer
38 mm 25 mm 316 SS SS-38M0-6-25M 913E24023 Contact Manufacturer
38 mm 30 mm 316 SS SS-38M0-6-30M 913E24024 Contact Manufacturer

Swagelok Co.

Bulkhead Straight Union Tube Fittings, Standard Inch Size

Compression tube fittings in a bulkhead body, where the two ends have identical standard size. These fittings are designed to go through a wall, such as a side wall of a plumbing module.
Tube OD Material Mfg P/N Encole P/N Price
1/16” 316 SS SS-100-61 914E1301 Contact Manufacturer
1/8” 316 SS SS-200-61 914E1302 Contact Manufacturer
3/16” 316 SS SS-300-61 914E1303 Contact Manufacturer
1/4” 316 SS SS-400-61 914E1304 Contact Manufacturer
5/16” 316 SS SS-500-61 914E1305 Contact Manufacturer
3/8” 316 SS SS-600-61 914E1306 Contact Manufacturer
1/2” 316 SS SS-810-61 914E1307 Contact Manufacturer
5/8” 316 SS SS-1010-61 914E1308 Contact Manufacturer
3/4” 316 SS SS-1210-61 914E1309 Contact Manufacturer
1” 316 SS SS-1610-61 914E13010 Contact Manufacturer
1-1/4” 316 SS SS-2000-61 914E13011 Contact Manufacturer
1-1/2” 316 SS SS-2400-61 914E13012 Contact Manufacturer
2” 316 SS SS-3200-61 914E13013 Contact Manufacturer

Swagelok Co.

Bulkhead Straight Tube Fitting Unions, Metric

Compression tube fittings in a bulkhead body, where the two ends have identical metric size. These fittings are designed to go through a wall, such as a side wall of a plumbing module.
Tube OD Material Mfg P/N Encole P/N Price
3 mm 316 SS SS-3M0-61 915E1501 Contact Manufacturer
4 mm 316 SS SS-4M0-61 915E1502 Contact Manufacturer
6 mm 316 SS SS-6M0-61 915E1503 Contact Manufacturer
8 mm 316 SS SS-8M0-61 915E1504 Contact Manufacturer
10 mm 316 SS SS-10M0-61 915E1505 Contact Manufacturer
12 mm 316 SS SS-12M0-61 915E1506 Contact Manufacturer
14 mm 316 SS SS-14M0-61 915E1507 Contact Manufacturer
15 mm 316 SS SS-15M0-61 915E1508 Contact Manufacturer
16 mm 316 SS SS-16M0-61 915E1509 Contact Manufacturer
18 mm 316 SS SS-18M0-61 915E15010 Contact Manufacturer
20 mm 316 SS SS-20M0-61 915E15011 Contact Manufacturer
25 mm 316 SS SS-25M0-61 915E15012 Contact Manufacturer
30 mm 316 SS SS-30M0-61 915E15013 Contact Manufacturer
32 mm 316 SS SS-32M0-61 915E15014 Contact Manufacturer
38 mm 316 SS SS-38M0-61 915E15015 Contact Manufacturer

Swagelok Co.

Bulkhead Straight Reducing Union Tube Fittings, Fractional Size

Compression tube fittings in a bulkhead body, where the two ends have different fractional sizes. These fittings are designed to go through a wall, such as a side wall of a plumbing cabinet or a panel.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
1/8” 1/16” 316 SS SS-200-61-1 916E401 Contact Manufacturer
1/4” 1/8” 316 SS SS-400-61-2 916E402 Contact Manufacturer
3/8” 1/4” 316 SS SS-600-61-4 916E403 Contact Manufacturer
1/2” 1/4” 316 SS SS-810-61-4 916E404 Contact Manufacturer

Swagelok Co.

Bulkhead Straight Reducing Union Tube Fittings, Metric to Fractional Size

Compression tube fitting in a bulkhead body, where one end has a metric size and the other end has a fractional size.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
6 mm 1/8” 316 SS SS-6M0-61-2 917E101 Contact Manufacturer

Swagelok Co.

Tube Fitting to NPT Connectors

Male connector fittings with a compression tube socket on one end, and NPT threads on the other end.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
1/16” NPT 1/16” 316 SS SS-100-1-1 918E5001 Contact Manufacturer
1/16” NPT 1/8” 316 SS SS-100-1-2 918E5002 Contact Manufacturer
1/16” NPT 1/4” 316 SS SS-100-1-4 918E5003 Contact Manufacturer
1/8” NPT 1/16” 316 SS SS-200-1-1 918E5004 Contact Manufacturer
1/8” NPT 1/8” 316 SS SS-200-1-2 918E5005 Contact Manufacturer
1/8” NPT 1/4” 316 SS SS-200-1-4 918E5006 Contact Manufacturer
1/8” NPT 3/8” 316 SS SS-200-1-6 918E5007 Contact Manufacturer
1/8” NPT 1/2” 316 SS SS-200-1-8 918E5008 Contact Manufacturer
3/16” NPT 1/8” 316 SS SS-300-1-2 918E5009 Contact Manufacturer
3/16” NPT 1/4” 316 SS SS-300-1-4 918E50010 Contact Manufacturer
1/4” NPT 1/16” 316 SS SS-400-1-1 918E50011 Contact Manufacturer
1/4” NPT 1/8” 316 SS SS-400-1-2 918E50012 Contact Manufacturer
1/4” NPT 1/4” 316 SS SS-400-1-4 918E50013 Contact Manufacturer
1/4” NPT 3/8” 316 SS SS-400-1-6 918E50014 Contact Manufacturer
1/4” NPT 1/2” 316 SS SS-400-1-8 918E50015 Contact Manufacturer
1/4” NPT 3/4” 316 SS SS-400-1-12 918E50016 Contact Manufacturer
5/16” NPT 1/8” 316 SS SS-500-1-2 918E50017 Contact Manufacturer
5/16” NPT 1/4” 316 SS SS-500-1-4 918E50018 Contact Manufacturer
5/16” NPT 3/8” 316 SS SS-500-1-6 918E50019 Contact Manufacturer
3/8” NPT 1/8” 316 SS SS-600-1-2 918E50020 Contact Manufacturer
3/8” NPT 1/4” 316 SS SS-600-1-4 918E50021 Contact Manufacturer
3/8” NPT 3/8” 316 SS SS-600-1-6 918E50022 Contact Manufacturer
3/8” NPT 1/2” 316 SS SS-600-1-8 918E50023 Contact Manufacturer
3/8” NPT 3/4” 316 SS SS-600-1-12 918E50024 Contact Manufacturer
3/8” NPT 1” 316 SS SS-600-1-16 918E50025 Contact Manufacturer
1/2” NPT 1/8” 316 SS SS-810-1-2 918E50026 Contact Manufacturer
1/2” NPT 1/4” 316 SS SS-810-1-4 918E50027 Contact Manufacturer
1/2” NPT 3/8” 316 SS SS-810-1-6 918E50028 Contact Manufacturer
1/2” NPT 1/2” 316 SS SS-810-1-8 918E50029 Contact Manufacturer
1/2” NPT 3/4” 316 SS SS-810-1-12 918E50030 Contact Manufacturer
1/2” NPT 1” 316 SS SS-810-1-16 918E50031 Contact Manufacturer
5/8” NPT 1/4” 316 SS SS-1010-1-4 918E50032 Contact Manufacturer
5/8” NPT 3/8” 316 SS SS-1010-1-6 918E50033 Contact Manufacturer
5/8” NPT 1/2” 316 SS SS-1010-1-8 918E50034 Contact Manufacturer
5/8” NPT 3/4” 316 SS SS-1010-1-12 918E50035 Contact Manufacturer
3/4” NPT 3/8” 316 SS SS-1210-1-6 918E50036 Contact Manufacturer
3/4” NPT 1/2” 316 SS SS-1210-1-8 918E50037 Contact Manufacturer
3/4” NPT 3/4” 316 SS SS-1210-1-12 918E50038 Contact Manufacturer
3/4” NPT 1” 316 SS SS-1210-1-16 918E50039 Contact Manufacturer
7/8” NPT 1/2” 316 SS SS-1410-1-8 918E50040 Contact Manufacturer
7/8” NPT 3/4” 316 SS SS-1410-1-12 918E50041 Contact Manufacturer
7/8” NPT 1” 316 SS SS-1410-1-16 918E50042 Contact Manufacturer
1” NPT 1/2” 316 SS SS-1610-1-8 918E50043 Contact Manufacturer
1” NPT 3/4” 316 SS SS-1610-1-12 918E50044 Contact Manufacturer
1” NPT 1” 316 SS SS-1610-1-16 918E50045 Contact Manufacturer
1-1/8” NPT 1” 316 SS SS-1810-1-16 918E50046 Contact Manufacturer
1-1/4” NPT 1” 316 SS SS-2000-1-16 918E50047 Contact Manufacturer
1-1/4” NPT 1-1/4” 316 SS SS-2000-1-20 918E50048 Contact Manufacturer
1-1/2” NPT 1-1/2” 316 SS SS-2400-1-24 918E50049 Contact Manufacturer
2” NPT 2” 316 SS SS-3200-1-32 918E50050 Contact Manufacturer

Swagelok Co.

Metirc Tube Fitting to NPT Connectors

Male connector fittings with a Metric compression tube socket on one end, and NPT threads on the other end.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
2 mm NPT 1/8” 316 SS SS-2M0-1-2 919E4601 Contact Manufacturer
3 mm NPT 1/8” 316 SS SS-3M0-1-2 919E4602 Contact Manufacturer
3 mm NPT 1/4” 316 SS SS-3M0-1-4 919E4603 Contact Manufacturer
4 mm NPT 1/8” 316 SS SS-4M0-1-2 919E4604 Contact Manufacturer
4 mm NPT 1/4” 316 SS SS-4M0-1-4 919E4605 Contact Manufacturer
6 mm NPT 1/8” 316 SS SS-6M0-1-2 919E4606 Contact Manufacturer
6 mm NPT 1/4” 316 SS SS-6M0-1-4 919E4607 Contact Manufacturer
6 mm NPT 3/8” 316 SS SS-6M0-1-6 919E4608 Contact Manufacturer
6 mm NPT 1/2” 316 SS SS-6M0-1-8 919E4609 Contact Manufacturer
8 mm NPT 1/8” 316 SS SS-8M0-1-2 919E46010 Contact Manufacturer
8 mm NPT 1/4” 316 SS SS-8M0-1-4 919E46011 Contact Manufacturer
8 mm NPT 3/8” 316 SS SS-8M0-1-6 919E46012 Contact Manufacturer
8 mm NPT 1/2” 316 SS SS-8M0-1-8 919E46013 Contact Manufacturer
10 mm NPT 1/8” 316 SS SS-10M0-1-2 919E46014 Contact Manufacturer
10 mm NPT 1/4” 316 SS SS-10M0-1-4 919E46015 Contact Manufacturer
10 mm NPT 3/8” 316 SS SS-10M0-1-6 919E46016 Contact Manufacturer
10 mm NPT 1/2” 316 SS SS-10M0-1-8 919E46017 Contact Manufacturer
10 mm NPT 3/4” 316 SS SS-10M0-1-12 919E46018 Contact Manufacturer
12 mm NPT 1/8” 316 SS SS-12M0-1-2 919E46019 Contact Manufacturer
12 mm NPT 1/4” 316 SS SS-12M0-1-4 919E46020 Contact Manufacturer
12 mm NPT 3/8” 316 SS SS-12M0-1-6 919E46021 Contact Manufacturer
12 mm NPT 1/2” 316 SS SS-12M0-1-8 919E46022 Contact Manufacturer
12 mm NPT 3/4” 316 SS SS-12M0-1-12 919E46023 Contact Manufacturer
14 mm NPT 1/4” 316 SS SS-14M0-1-4 919E46024 Contact Manufacturer
14 mm NPT 3/8” 316 SS SS-14M0-1-6 919E46025 Contact Manufacturer
14 mm NPT 1/2” 316 SS SS-14M0-1-8 919E46026 Contact Manufacturer
15 mm NPT 1/2” 316 SS SS-15M0-1-8 919E46027 Contact Manufacturer
16 mm NPT 3/8” 316 SS SS-16M0-1-6 919E46028 Contact Manufacturer
16 mm NPT 1/2” 316 SS SS-16M0-1-8 919E46029 Contact Manufacturer
16 mm NPT 3/4” 316 SS SS-16M0-1-12 919E46030 Contact Manufacturer
18 mm NPT 1/2” 316 SS SS-18M0-1-8 919E46031 Contact Manufacturer
18 mm NPT 3/4” 316 SS SS-18M0-1-12 919E46032 Contact Manufacturer
20 mm NPT 1/2” 316 SS SS-20M0-1-8 919E46033 Contact Manufacturer
20 mm NPT 3/4” 316 SS SS-20M0-1-12 919E46034 Contact Manufacturer
22 mm NPT 3/4” 316 SS SS-22M0-1-12 919E46035 Contact Manufacturer
22 mm NPT 1” 316 SS SS-22M0-1-16 919E46036 Contact Manufacturer
25 mm NPT 1/2” 316 SS SS-25M0-1-8 919E46037 Contact Manufacturer
25 mm NPT 3/4” 316 SS SS-25M0-1-12 919E46038 Contact Manufacturer
25 mm NPT 1” 316 SS SS-25M0-1-16 919E46039 Contact Manufacturer
28 mm NPT 1” 316 SS SS-28M0-1-16 919E46040 Contact Manufacturer
28 mm NPT 1-1/4” 316 SS SS-28M0-1-20 919E46041 Contact Manufacturer
28 mm NPT 1” Brass B-28M0-1-16 919E46042 Contact Manufacturer
28 mm NPT 1-1/4” Brass B-28M0-1-20 919E46043 Contact Manufacturer
30 mm NPT 1-1/4” 316 SS SS-30M0-1-20 919E46044 Contact Manufacturer
32 mm NPT 1-1/4” 316 SS SS-32M0-1-20 919E46045 Contact Manufacturer
38 mm NPT 1-1/2” 316 SS SS-38M0-1-24 919E46046 Contact Manufacturer

Swagelok Co.

ISO/BSPT Tapered Thread Tube Fitting Connectors

Straight tube fitting connectors with British Whitworth tapered, BSPT threads on one end of the fitting.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
1/8” BSPT 1/8” 316 SS SS-200-1-2RT 920E2301 Contact Manufacturer
1/8” BSPT 1/4” 316 SS SS-200-1-4RT 920E2302 Contact Manufacturer
1/4” BSPT 1/8” 316 SS SS-400-1-2RT 920E2303 Contact Manufacturer
1/4” BSPT 1/4” 316 SS SS-400-1-4RT 920E2304 Contact Manufacturer
1/4” BSPT 3/8” 316 SS SS-400-1-6RT 920E2305 Contact Manufacturer
1/4” BSPT 1/2” 316 SS SS-400-1-8RT 920E2306 Contact Manufacturer
5/16” BSPT 1/8” 316 SS SS-500-1-2RT 920E2307 Contact Manufacturer
5/16” BSPT 1/4” 316 SS SS-500-1-4RT 920E2308 Contact Manufacturer
3/8” BSPT 1/8” 316 SS SS-600-1-2RT 920E2309 Contact Manufacturer
3/8” BSPT 1/4” 316 SS SS-600-1-4RT 920E23010 Contact Manufacturer
3/8” BSPT 3/8” 316 SS SS-600-1-6RT 920E23011 Contact Manufacturer
3/8” BSPT 1/2” 316 SS SS-600-1-8RT 920E23012 Contact Manufacturer
3/8” BSPT 3/4” 316 SS SS-600-1-12RT 920E23013 Contact Manufacturer
1/2” BSPT 1/4” 316 SS SS-810-1-4RT 920E23014 Contact Manufacturer
1/2” BSPT 3/8” 316 SS SS-810-1-6RT 920E23015 Contact Manufacturer
1/2” BSPT 1/2” 316 SS SS-810-1-8RT 920E23016 Contact Manufacturer
1/2” BSPT 3/4” 316 SS SS-810-1-12RT 920E23017 Contact Manufacturer
5/8” BSPT 1/2” 316 SS SS-1010-1-8RT 920E23018 Contact Manufacturer
3/4” BSPT 3/4” 316 SS SS-1210-1-12RT 920E23019 Contact Manufacturer
3/4” BSPT 1” 316 SS SS-1210-1-16RT 920E23020 Contact Manufacturer
1” BSPT 3/4” 316 SS SS-1610-1-12RT 920E23021 Contact Manufacturer
1” BSPT 1” 316 SS SS-1610-1-16RT 920E23022 Contact Manufacturer
1-1/4” BSPT 1-1/4” 316 SS SS-2000-1-20RT 920E23023 Contact Manufacturer

Swagelok Co.

ISO/BSPT Thread Tube Fitting Connectors, Metric

Metric straight tube fitting connectors with British Whitworth tapered, BSPT threads on one end of the fitting.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
2 mm BSPT 1/8” 316 SS SS-2M0-1-2RT 921E4501 Contact Manufacturer
3 mm BSPT 1/8” 316 SS SS-3M0-1-2RT 921E4502 Contact Manufacturer
3 mm BSPT 1/4” 316 SS SS-3M0-1-4RT 921E4503 Contact Manufacturer
4 mm BSPT 1/8” 316 SS SS-4M0-1-2RT 921E4504 Contact Manufacturer
4 mm BSPT 1/4” 316 SS SS-4M0-1-4RT 921E4505 Contact Manufacturer
6 mm BSPT 1/8” 316 SS SS-6M0-1-2RT 921E4506 Contact Manufacturer
6 mm BSPT 1/4” 316 SS SS-6M0-1-4RT 921E4507 Contact Manufacturer
6 mm BSPT 3/8” 316 SS SS-6M0-1-6RT 921E4508 Contact Manufacturer
6 mm BSPT 1/2” 316 SS SS-6M0-1-8RT 921E4509 Contact Manufacturer
8 mm BSPT 1/8” 316 SS SS-8M0-1-2RT 921E45010 Contact Manufacturer
8 mm BSPT 1/4” 316 SS SS-8M0-1-4RT 921E45011 Contact Manufacturer
8 mm BSPT 3/8” 316 SS SS-8M0-1-6RT 921E45012 Contact Manufacturer
8 mm BSPT 1/2” 316 SS SS-8M0-1-8RT 921E45013 Contact Manufacturer
10 mm BSPT 1/8” 316 SS SS-10M0-1-2RT 921E45014 Contact Manufacturer
10 mm BSPT 1/4” 316 SS SS-10M0-1-4RT 921E45015 Contact Manufacturer
10 mm BSPT 3/8” 316 SS SS-10M0-1-6RT 921E45016 Contact Manufacturer
10 mm BSPT 1/2” 316 SS SS-10M0-1-8RT 921E45017 Contact Manufacturer
10 mm BSPT 3/4” 316 SS SS-10M0-1-12RT 921E45018 Contact Manufacturer
12 mm BSPT 1/4” 316 SS SS-12M0-1-4RT 921E45019 Contact Manufacturer
12 mm BSPT 3/8” 316 SS SS-12M0-1-6RT 921E45020 Contact Manufacturer
12 mm BSPT 1/2” 316 SS SS-12M0-1-8RT 921E45021 Contact Manufacturer
12 mm BSPT 3/4” 316 SS SS-12M0-1-12RT 921E45022 Contact Manufacturer
14 mm BSPT 1/4” 316 SS SS-14M0-1-4RT 921E45023 Contact Manufacturer
14 mm BSPT 3/8” 316 SS SS-14M0-1-6RT 921E45024 Contact Manufacturer
15 mm BSPT 1/2” 316 SS SS-15M0-1-8RT 921E45025 Contact Manufacturer
16 mm BSPT 1/4” 316 SS SS-16M0-1-4RT 921E45026 Contact Manufacturer
16 mm BSPT 3/8” 316 SS SS-16M0-1-6RT 921E45027 Contact Manufacturer
16 mm BSPT 1/2” 316 SS SS-16M0-1-8RT 921E45028 Contact Manufacturer
16 mm BSPT 3/4” 316 SS SS-16M0-1-12RT 921E45029 Contact Manufacturer
18 mm BSPT 1/2” 316 SS SS-18M0-1-8RT 921E45030 Contact Manufacturer
18 mm BSPT 3/4” 316 SS SS-18M0-1-12RT 921E45031 Contact Manufacturer
20 mm BSPT 1/2” 316 SS SS-20M0-1-8RT 921E45032 Contact Manufacturer
20 mm BSPT 3/4” 316 SS SS-20M0-1-12RT 921E45033 Contact Manufacturer
22 mm BSPT 3/4” 316 SS SS-22M0-1-12RT 921E45034 Contact Manufacturer
22 mm BSPT 1” 316 SS SS-22M0-1-16RT 921E45035 Contact Manufacturer
25 mm BSPT 1/2” 316 SS SS-25M0-1-8RT 921E45036 Contact Manufacturer
25 mm BSPT 3/4” 316 SS SS-25M0-1-12RT 921E45037 Contact Manufacturer
25 mm BSPT 1” 316 SS SS-25M0-1-16RT 921E45038 Contact Manufacturer
28 mm BSPT 1” 316 SS SS-28M0-1-16RT 921E45039 Contact Manufacturer
28 mm BSPT 1-1/4” 316 SS SS-28M0-1-20RT 921E45040 Contact Manufacturer
28 mm BSPT 1” Brass B-28M0-1-16RT 921E45041 Contact Manufacturer
28 mm BSPT 1-1/4” Brass B-28M0-1-20RT 921E45042 Contact Manufacturer
30 mm BSPT 1-1/4” 316 SS SS-30M0-1-20RT 921E45043 Contact Manufacturer
32 mm BSPT 1-1/4” 316 SS SS-32M0-1-20RT 921E45044 Contact Manufacturer
38 mm BSPT 1-1/2” 316 SS SS-38M0-1-24RT 921E45045 Contact Manufacturer

Swagelok Co.

ISO/BSPP Parallel Thread Tube Fitting Connectors

Male connector tube fittings with British Whitworth Parallel, BSPP Thread on one end of the fitting.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
1/8” BSPP 1/8” 316 SS SS-200-1-2RS 922E1901 Contact Manufacturer
1/8” BSPP 1/4” 316 SS SS-200-1-4RS 922E1902 Contact Manufacturer
1/8” BSPP 3/8” 316 SS SS-200-1-6RS 922E1903 Contact Manufacturer
1/4” BSPP 1/8” 316 SS SS-400-1-2RS 922E1904 Contact Manufacturer
1/4” BSPP 1/4” 316 SS SS-400-1-4RS 922E1905 Contact Manufacturer
1/4” BSPP 3/8” 316 SS SS-400-1-6RS 922E1906 Contact Manufacturer
1/4” BSPP 1/2” 316 SS SS-400-1-8RS 922E1907 Contact Manufacturer
3/8” BSPP 1/8” 316 SS SS-600-1-2RS 922E1908 Contact Manufacturer
3/8” BSPP 1/4” 316 SS SS-600-1-4RS 922E1909 Contact Manufacturer
3/8” BSPP 3/8” 316 SS SS-600-1-6RS 922E19010 Contact Manufacturer
3/8” BSPP 1/2” 316 SS SS-600-1-8RS 922E19011 Contact Manufacturer
1/2” BSPP 1/4” 316 SS SS-810-1-4RS 922E19012 Contact Manufacturer
1/2” BSPP 3/8” 316 SS SS-810-1-6RS 922E19013 Contact Manufacturer
1/2” BSPP 1/2” 316 SS SS-810-1-8RS 922E19014 Contact Manufacturer
3/4” BSPP 1/2” 316 SS SS-1210-1-8RS 922E19015 Contact Manufacturer
3/4” BSPP 3/4” 316 SS SS-1210-1-12RS 922E19016 Contact Manufacturer
1” BSPP 1/2” 316 SS SS-1610-1-8RS 922E19017 Contact Manufacturer
1” BSPP 3/4” 316 SS SS-1610-1-12RS 922E19018 Contact Manufacturer
1” BSPP 1” 316 SS SS-1610-1-16RS 922E19019 Contact Manufacturer

Swagelok Co.

ISO/BSPP Parallel Thread Tube Fitting Connectors, Metric

Metric straight tube fitting connectors with British Whitworth parallel, BSPT threads on one end of the fitting.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
2 mm BSPP 1/8” 316 SS SS-2M0-1-2RS 923E4201 Contact Manufacturer
3 mm BSPP 1/8” 316 SS SS-3M0-1-2RS 923E4202 Contact Manufacturer
3 mm BSPP 1/4” 316 SS SS-3M0-1-4RS 923E4203 Contact Manufacturer
4 mm BSPP 1/8” 316 SS SS-4M0-1-2RS 923E4204 Contact Manufacturer
6 mm BSPP 1/8” 316 SS SS-6M0-1-2RS 923E4205 Contact Manufacturer
6 mm BSPP 1/4” 316 SS SS-6M0-1-4RS 923E4206 Contact Manufacturer
6 mm BSPP 3/8” 316 SS SS-6M0-1-6RS 923E4207 Contact Manufacturer
6 mm BSPP 1/2” 316 SS SS-6M0-1-8RS 923E4208 Contact Manufacturer
8 mm BSPP 1/8” 316 SS SS-8M0-1-2RS 923E4209 Contact Manufacturer
8 mm BSPP 1/4” 316 SS SS-8M0-1-4RS 923E42010 Contact Manufacturer
8 mm BSPP 3/8” 316 SS SS-8M0-1-6RS 923E42011 Contact Manufacturer
8 mm BSPP 1/2” 316 SS SS-8M0-1-8RS 923E42012 Contact Manufacturer
10 mm BSPP 1/4” 316 SS SS-10M0-1-4RS 923E42013 Contact Manufacturer
10 mm BSPP 3/8” 316 SS SS-10M0-1-6RS 923E42014 Contact Manufacturer
10 mm BSPP 1/2” 316 SS SS-10M0-1-8RS 923E42015 Contact Manufacturer
12 mm BSPP 1/4” 316 SS SS-12M0-1-4RS 923E42016 Contact Manufacturer
12 mm BSPP 3/8” 316 SS SS-12M0-1-6RS 923E42017 Contact Manufacturer
12 mm BSPP 1/2” 316 SS SS-12M0-1-8RS 923E42018 Contact Manufacturer
12 mm BSPP 3/4” 316 SS SS-12M0-1-12RS 923E42019 Contact Manufacturer
14 mm BSPP 3/8” 316 SS SS-14M0-1-6RS 923E42020 Contact Manufacturer
14 mm BSPP 1/2” 316 SS SS-14M0-1-8RS 923E42021 Contact Manufacturer
15 mm BSPP 3/8” 316 SS SS-15M0-1-6RS 923E42022 Contact Manufacturer
15 mm BSPP 1/2” 316 SS SS-15M0-1-8RS 923E42023 Contact Manufacturer
15 mm BSPP 3/4” 316 SS SS-15M0-1-12RS 923E42024 Contact Manufacturer
16 mm BSPP 3/8” 316 SS SS-16M0-1-6RS 923E42025 Contact Manufacturer
16 mm BSPP 1/2” 316 SS SS-16M0-1-8RS 923E42026 Contact Manufacturer
16 mm BSPP 3/4” 316 SS SS-16M0-1-12RS 923E42027 Contact Manufacturer
18 mm BSPP 1/2” 316 SS SS-18M0-1-8RS 923E42028 Contact Manufacturer
18 mm BSPP 3/4” 316 SS SS-18M0-1-12RS 923E42029 Contact Manufacturer
20 mm BSPP 1/2” 316 SS SS-20M0-1-8RS 923E42030 Contact Manufacturer
20 mm BSPP 3/4” 316 SS SS-20M0-1-12RS 923E42031 Contact Manufacturer
22 mm BSPP 3/4” 316 SS SS-22M0-1-12RS 923E42032 Contact Manufacturer
22 mm BSPP 1” 316 SS SS-22M0-1-16RS 923E42033 Contact Manufacturer
25 mm BSPP 3/4” 316 SS SS-25M0-1-12RS 923E42034 Contact Manufacturer
25 mm BSPP 1” 316 SS SS-25M0-1-16RS 923E42035 Contact Manufacturer
28 mm BSPP 1” 316 SS SS-28M0-1-16RS 923E42036 Contact Manufacturer
28 mm BSPP 1-1/4” 316 SS SS-28M0-1-20RS 923E42037 Contact Manufacturer
28 mm BSPP 1” Brass B-28M0-1-16RS 923E42038 Contact Manufacturer
28 mm BSPP 1-1/4” Brass B-28M0-1-20RS 923E42039 Contact Manufacturer
30 mm BSPP 1-1/4” 316 SS SS-30M0-1-20RS 923E42040 Contact Manufacturer
32 mm BSPP 1-1/4” 316 SS SS-32M0-1-20RS 923E42041 Contact Manufacturer
38 mm BSPP 1-1/2” 316 SS SS-38M0-1-24RS 923E42042 Contact Manufacturer

Swagelok Co.

Tube Fitting to NPT Bulkhead Connectors

Bulkhead male connector fittings with a compression tube socket on one end, and NPT threads on the other end. These fittings are designed to go through a side wall of a plumbing cabinet, or a flat panel.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
1/8” NPT 1/8” 316 SS SS-200-11-2 926E1301 Contact Manufacturer
1/4” NPT 1/8” 316 SS SS-400-11-2 926E1302 Contact Manufacturer
1/4” NPT 1/4” 316 SS SS-400-11-4 926E1303 Contact Manufacturer
3/8” NPT 1/4” 316 SS SS-600-11-4 926E1304 Contact Manufacturer
3/8” NPT 3/8” 316 SS SS-600-11-6 926E1305 Contact Manufacturer
3/8” NPT 1/2” 316 SS SS-600-11-8 926E1306 Contact Manufacturer
1/2” NPT 3/8” 316 SS SS-810-11-6 926E1307 Contact Manufacturer
1/2” NPT 1/2” 316 SS SS-810-11-8 926E1308 Contact Manufacturer
3/4” NPT 3/4” 316 SS SS-1210-11-12 926E1309 Contact Manufacturer
1” NPT 1” 316 SS SS-1610-11-16 926E13010 Contact Manufacturer
6 mm NPT 1/8” 316 SS SS-6M0-11-2 926E13011 Contact Manufacturer
6 mm NPT 1/4” 316 SS SS-6M0-11-4 926E13012 Contact Manufacturer
12 mm NPT 1/2” 316 SS SS-12M0-11-8 926E13013 Contact Manufacturer

Swagelok Co.

Tube Fitting to SAE Male Connectors

Tube fitting connectors with compression tube socket on one end and a SAE boss with straight threads on the other end.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
1/8” SAE-2 316 SS SS-200-1-2ST 927E3401 Contact Manufacturer
1/8” SAE-4 316 SS SS-200-1-4ST 927E3402 Contact Manufacturer
1/8” SAE-6 316 SS SS-200-1-6ST 927E3403 Contact Manufacturer
1/4” SAE-2 316 SS SS-400-1-2ST 927E3404 Contact Manufacturer
1/4” SAE-4 316 SS SS-400-1-4ST 927E3405 Contact Manufacturer
1/4” SAE-6 316 SS SS-400-1-6ST 927E3406 Contact Manufacturer
1/4” SAE-8 316 SS SS-400-1-8ST 927E3407 Contact Manufacturer
1/4” SAE-10 316 SS SS-400-1-10ST 927E3408 Contact Manufacturer
5/16” SAE-5 316 SS SS-500-1-5ST 927E3409 Contact Manufacturer
3/8” SAE-4 316 SS SS-600-1-4ST 927E34010 Contact Manufacturer
3/8” SAE-6 316 SS SS-600-1-6ST 927E34011 Contact Manufacturer
3/8” SAE-8 316 SS SS-600-1-8ST 927E34012 Contact Manufacturer
3/8” SAE-10 316 SS SS-600-1-10ST 927E34013 Contact Manufacturer
1/2” SAE-6 316 SS SS-810-1-6ST 927E34014 Contact Manufacturer
1/2” SAE-8 316 SS SS-810-1-8ST 927E34015 Contact Manufacturer
1/2” SAE-10 316 SS SS-810-1-10ST 927E34016 Contact Manufacturer
1/2” SAE-12 316 SS SS-810-1-12ST 927E34017 Contact Manufacturer
5/8” SAE-8 316 SS SS-1010-1-8ST 927E34018 Contact Manufacturer
5/8” SAE-10 316 SS SS-1010-1-10ST 927E34019 Contact Manufacturer
3/4” SAE-8 316 SS SS-1210-1-8ST 927E34020 Contact Manufacturer
3/4” SAE-12 316 SS SS-1210-1-12ST 927E34021 Contact Manufacturer
3/4” SAE-16 316 SS SS-1210-1-16ST 927E34022 Contact Manufacturer
7/8” SAE-14 316 SS SS-1410-1-14ST 927E34023 Contact Manufacturer
1” SAE-12 316 SS SS-1610-1-12ST 927E34024 Contact Manufacturer
1” SAE-16 316 SS SS-1610-1-16ST 927E34025 Contact Manufacturer
1-1/4” SAE-20 316 SS SS-2000-1-20ST 927E34026 Contact Manufacturer
1-1/2” SAE-24 316 SS SS-2400-1-24ST 927E34027 Contact Manufacturer
2” SAE-32 316 SS SS-3200-1-32ST 927E34028 Contact Manufacturer
6 mm SAE-6 316 SS SS-6M0-1-6ST 927E34029 Contact Manufacturer
10 mm SAE-6 316 SS SS-10M0-1-6ST 927E34030 Contact Manufacturer
10 mm SAE-8 316 SS SS-10M0-1-8ST 927E34031 Contact Manufacturer
12 mm SAE-4 316 SS SS-12M0-1-4ST 927E34032 Contact Manufacturer
12 mm SAE-6 316 SS SS-12M0-1-6ST 927E34033 Contact Manufacturer
12 mm SAE-8 316 SS SS-12M0-1-8ST 927E34034 Contact Manufacturer

Swagelok Co.

Tube Fitting to Long SAE Male Connectors

Long tube fitting connectors with compression tube socket on one end and a SAE boss with straight threads on the other end.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
1/4” SAE-4 316 SS SS-400-1L-4ST 928E201 Contact Manufacturer
1/2” SAE-8 316 SS SS-810-1L-8ST 928E202 Contact Manufacturer

Swagelok Co.

Tube Fitting Connectors SAE/MS Thread with O-ring Face Seal

Connector, tube fittings to SAE/MS straight thread with face seal.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
1/16” Thread 5/16-24 316 SS SS-200-1-OR 929E901 Contact Manufacturer
1/8” Thread 5/16-24 316 SS SS-200-1-OR 929E902 Contact Manufacturer
3/16” Thread 3/8-24 316 SS SS-300-1-OR 929E903 Contact Manufacturer
1/4” Thread 7/16-20 316 SS SS-400-1-OR 929E904 Contact Manufacturer
5/16” Thread 1/2-20 316 SS SS-500-1-OR 929E905 Contact Manufacturer
3/8” Thread 9/16-18 316 SS SS-600-1-OR 929E906 Contact Manufacturer
1/2” Thread 3/4-16 316 SS SS-810-1-OR 929E907 Contact Manufacturer
3/4” Thread 1 1/16-12 316 SS SS-1210-1-OR 929E908 Contact Manufacturer
1” Thread 1 5/16-12 316 SS SS-1610-1-OR 929E909 Contact Manufacturer

Swagelok Co.

AN Tube Flare to Tube Compression Connectors

Tube fitting connectors with male AN tube flare on one end.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
1/16” AN-2, Tube Flare 1/8” 316 SS SS-100-6-2AN 930E1001 Contact Manufacturer
1/8” AN-2, Tube Flare 1/8” 316 SS SS-200-6-2AN 930E1002 Contact Manufacturer
1/8” AN-4, Tube Flare 1/4” 316 SS SS-200-6-4AN 930E1003 Contact Manufacturer
1/4” AN-4, Tube Flare 1/4” 316 SS SS-400-6-4AN 930E1004 Contact Manufacturer
5/16” AN-5, Tube Flare 5/16” 316 SS SS-500-6-5AN 930E1005 Contact Manufacturer
3/8” AN-4, Tube Flare 1/4” 316 SS SS-600-6-4AN 930E1006 Contact Manufacturer
3/8” AN-6, Tube Flare 3/8” 316 SS SS-600-6-6AN 930E1007 Contact Manufacturer
1/2” AN-8, Tube Flare 1/2” 316 SS SS-810-6-8AN 930E1008 Contact Manufacturer
3/4” AN-12, Tube Flare 3/4” 316 SS SS-1210-6-12AN 930E1009 Contact Manufacturer
1” AN-16, Tube Flare 1” 316 SS SS-1610-6-16AN 930E10010 Contact Manufacturer

Swagelok Co.

Bulkhead AN Tube Flare to Tube Compression Connectors

Bulkhead tube fitting connectors with male AN tube flare on one end. These fittings are designed to go through a side wall of a plumbing cabinet or a panel.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
1/4” AN-4, Tube Flare 1/4” 316 SS SS-400-61-4AN 931E501 Contact Manufacturer
3/8” AN-6, Tube Flare 3/8” 316 SS SS-600-61-6AN 931E502 Contact Manufacturer
1/2” AN-8, Tube Flare 1/2” 316 SS SS-810-61-8AN 931E503 Contact Manufacturer
3/4” AN-12, Tube Flare 3/4” 316 SS SS-1210-61-12AN 931E504 Contact Manufacturer
1” AN-16, Tube Flare 1” 316 SS SS-1610-61-16AN 931E505 Contact Manufacturer

Swagelok Co.

Straight Tube Fitting Connectors with Tube Socket Weld

Tube fitting connectors where one end is a weld socket ready for orbital welding of a tube.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
1/8” Tube Socket Weld 1/8” 316 SS SS-200-6-2W 932E601 Contact Manufacturer
1/4” Tube Socket Weld 1/4” 316 SS SS-400-6-4W 932E602 Contact Manufacturer
3/8” Tube Socket Weld 3/8” 316 SS SS-600-6-6W 932E603 Contact Manufacturer
1/2” Tube Socket Weld 1/2” 316 SS SS-810-6-8W 932E604 Contact Manufacturer
3/4” Tube Socket Weld 3/4” 316 SS SS-1210-6-12W 932E605 Contact Manufacturer
1” Tube Socket Weld 1” 316 SS SS-1610-6-16W 932E606 Contact Manufacturer

Swagelok Co.

Pipe Weld Tube Fittings, Fractional Size

Tube fittings with a male pipe weld on one end.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
1/8” Pipe Weld 1/8” 316 SS SS-200-1-2W 933E2201 Contact Manufacturer
3/16” Pipe Weld 1/8” 316 SS SS-300-1-2W 933E2202 Contact Manufacturer
3/16” Pipe Weld 1/4” 316 SS SS-300-1-4W 933E2203 Contact Manufacturer
1/4” Pipe Weld 1/8” 316 SS SS-400-1-2W 933E2204 Contact Manufacturer
1/4” Pipe Weld 1/4” 316 SS SS-400-1-4W 933E2205 Contact Manufacturer
5/16” Pipe Weld 1/8” 316 SS SS-500-1-2W 933E2206 Contact Manufacturer
5/16” Pipe Weld 1/4” 316 SS SS-500-1-4W 933E2207 Contact Manufacturer
3/8” Pipe Weld 1/4” 316 SS SS-600-1-4W 933E2208 Contact Manufacturer
3/8” Pipe Weld 3/8” 316 SS SS-600-1-6W 933E2209 Contact Manufacturer
3/8” Pipe Weld 1/2” 316 SS SS-600-1-8W 933E22010 Contact Manufacturer
3/8” Pipe Weld 3/4” 316 SS SS-600-1-12W 933E22011 Contact Manufacturer
1/2” Pipe Weld 3/8” 316 SS SS-810-1-6W 933E22012 Contact Manufacturer
1/2” Pipe Weld 1/2” 316 SS SS-810-1-8W 933E22013 Contact Manufacturer
1/2” Pipe Weld 3/4” 316 SS SS-810-1-12W 933E22014 Contact Manufacturer
1/2” Pipe Weld 1” 316 SS SS-810-1-16W 933E22015 Contact Manufacturer
5/8” Pipe Weld 1/2” 316 SS SS-1010-1-8W 933E22016 Contact Manufacturer
3/4” Pipe Weld 1/2” 316 SS SS-1210-1-8W 933E22017 Contact Manufacturer
3/4” Pipe Weld 3/4” 316 SS SS-1210-1-12W 933E22018 Contact Manufacturer
1” Pipe Weld 1” 316 SS SS-1610-1-16W 933E22019 Contact Manufacturer
1-1/4” Pipe Weld 1-1/4” 316 SS SS-2000-1-20W 933E22020 Contact Manufacturer
1-1/2” Pipe Weld 1-1/2” 316 SS SS-2400-1-24W 933E22021 Contact Manufacturer
2” Pipe Weld 2” 316 SS SS-3200-1-32W 933E22022 Contact Manufacturer

Swagelok Co.

Pipe Weld Tube Fittings, Metric to Fractional Size

Tube fittings with metric compression tube size on one end and a pipe weld on the other end.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
3 mm Pipe Weld 1/8” 316 SS SS-3M0-1-2W 934E2101 Contact Manufacturer
4 mm Pipe Weld 1/8” 316 SS SS-4M0-1-2W 934E2102 Contact Manufacturer
6 mm Pipe Weld 1/8” 316 SS SS-6M0-1-2W 934E2103 Contact Manufacturer
6 mm Pipe Weld 1/4” 316 SS SS-6M0-1-4W 934E2104 Contact Manufacturer
8 mm Pipe Weld 1/8” 316 SS SS-8M0-1-2W 934E2105 Contact Manufacturer
8 mm Pipe Weld 1/4” 316 SS SS-8M0-1-4W 934E2106 Contact Manufacturer
8 mm Pipe Weld 1/2” 316 SS SS-8M0-1-8W 934E2107 Contact Manufacturer
10 mm Pipe Weld 1/4” 316 SS SS-10M0-1-4W 934E2108 Contact Manufacturer
10 mm Pipe Weld 3/8” 316 SS SS-10M0-1-6W 934E2109 Contact Manufacturer
10 mm Pipe Weld 1/2” 316 SS SS-10M0-1-8W 934E21010 Contact Manufacturer
12 mm Pipe Weld 1/4” 316 SS SS-12M0-1-4W 934E21011 Contact Manufacturer
12 mm Pipe Weld 3/8” 316 SS SS-12M0-1-6W 934E21012 Contact Manufacturer
12 mm Pipe Weld 1/2” 316 SS SS-12M0-1-8W 934E21013 Contact Manufacturer
12 mm Pipe Weld 3/4” 316 SS SS-12M0-1-12W 934E21014 Contact Manufacturer
14 mm Pipe Weld 3/8” 316 SS SS-14M0-1-6W 934E21015 Contact Manufacturer
15 mm Pipe Weld 1/2” 316 SS SS-15M0-1-8W 934E21016 Contact Manufacturer
16 mm Pipe Weld 1/2” 316 SS SS-16M0-1-8W 934E21017 Contact Manufacturer
18 mm Pipe Weld 1/2” 316 SS SS-18M0-1-8W 934E21018 Contact Manufacturer
30 mm Pipe Weld 1-1/4” 316 SS SS-30M0-1-20W 934E21019 Contact Manufacturer
32 mm Pipe Weld 1-1/4” 316 SS SS-32M0-1-20W 934E21020 Contact Manufacturer
38 mm Pipe Weld 1-1/2” 316 SS SS-38M0-1-24W 934E21021 Contact Manufacturer

Swagelok Co.

Female NPT Tube Fitting Connectors

Female connectors having standard size compression tube socket on one end and a female NPT port on the other end.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
1/16” Female NPT 1/16” 316 SS SS-100-7-1 935E3101 Contact Manufacturer
1/16” Female NPT 1/8” 316 SS SS-100-7-2 935E3102 Contact Manufacturer
1/8” Female NPT 1/8” 316 SS SS-200-7-2 935E3103 Contact Manufacturer
1/8” Female NPT 1/4” 316 SS SS-200-7-4 935E3104 Contact Manufacturer
3/16” Female NPT 1/8” 316 SS SS-300-7-2 935E3105 Contact Manufacturer
1/4” Female NPT 1/8” 316 SS SS-400-7-2 935E3106 Contact Manufacturer
1/4” Female NPT 1/4” 316 SS SS-400-7-4 935E3107 Contact Manufacturer
1/4” Female NPT 3/8” 316 SS SS-400-7-6 935E3108 Contact Manufacturer
1/4” Female NPT 1/2” 316 SS SS-400-7-8 935E3109 Contact Manufacturer
5/16” Female NPT 1/8” 316 SS SS-500-7-2 935E31010 Contact Manufacturer
5/16” Female NPT 1/4” 316 SS SS-500-7-4 935E31011 Contact Manufacturer
3/8” Female NPT 1/8” 316 SS SS-600-7-2 935E31012 Contact Manufacturer
3/8” Female NPT 1/4” 316 SS SS-600-7-4 935E31013 Contact Manufacturer
3/8” Female NPT 3/8” 316 SS SS-600-7-6 935E31014 Contact Manufacturer
3/8” Female NPT 1/2” 316 SS SS-600-7-8 935E31015 Contact Manufacturer
3/8” Female NPT 3/4” 316 SS SS-600-7-12 935E31016 Contact Manufacturer
1/2” Female NPT 1/4” 316 SS SS-810-7-4 935E31017 Contact Manufacturer
1/2” Female NPT 3/8” 316 SS SS-810-7-6 935E31018 Contact Manufacturer
1/2” Female NPT 1/2” 316 SS SS-810-7-8 935E31019 Contact Manufacturer
1/2” Female NPT 3/4” 316 SS SS-810-7-12 935E31020 Contact Manufacturer
5/8” Female NPT 3/8” 316 SS SS-1010-7-6 935E31021 Contact Manufacturer
5/8” Female NPT 1/2” 316 SS SS-1010-7-8 935E31022 Contact Manufacturer
5/8” Female NPT 3/4” 316 SS SS-1010-7-12 935E31023 Contact Manufacturer
3/4” Female NPT 1/2” 316 SS SS-1210-7-8 935E31024 Contact Manufacturer
3/4” Female NPT 3/4” 316 SS SS-1210-7-12 935E31025 Contact Manufacturer
7/8” Female NPT 3/4” 316 SS SS-1410-7-12 935E31026 Contact Manufacturer
1” Female NPT 3/4” 316 SS SS-1610-7-12 935E31027 Contact Manufacturer
1” Female NPT 1” 316 SS SS-1610-7-16 935E31028 Contact Manufacturer
1-1/4” Female NPT 1-1/4” 316 SS SS-2000-7-20 935E31029 Contact Manufacturer
1-1/2” Female NPT 1-1/2” 316 SS SS-2400-7-24 935E31030 Contact Manufacturer
2” Female NPT 2” 316 SS SS-3200-7-32 935E31031 Contact Manufacturer

Swagelok Co.

Female NPT Tube Fitting Connectors, Metric

Female connectors having Metric size compression tube socket on one end and a female NPT port on the other end.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
3 mm Female NPT 1/8” 316 SS SS-3M0-7-2 936E2501 Contact Manufacturer
3 mm Female NPT 1/4” 316 SS SS-3M0-7-4 936E2502 Contact Manufacturer
4 mm Female NPT 1/8” 316 SS SS-4M0-7-2 936E2503 Contact Manufacturer
6 mm Female NPT 1/8” 316 SS SS-6M0-7-2 936E2504 Contact Manufacturer
6 mm Female NPT 1/4” 316 SS SS-6M0-7-4 936E2505 Contact Manufacturer
6 mm Female NPT 3/8” 316 SS SS-6M0-7-6 936E2506 Contact Manufacturer
6 mm Female NPT 1/2” 316 SS SS-6M0-7-8 936E2507 Contact Manufacturer
8 mm Female NPT 1/8” 316 SS SS-8M0-7-2 936E2508 Contact Manufacturer
8 mm Female NPT 1/4” 316 SS SS-8M0-7-4 936E2509 Contact Manufacturer
8 mm Female NPT 3/8” 316 SS SS-8M0-7-6 936E25010 Contact Manufacturer
8 mm Female NPT 1/2” 316 SS SS-8M0-7-8 936E25011 Contact Manufacturer
10 mm Female NPT 1/4” 316 SS SS-10M0-7-4 936E25012 Contact Manufacturer
10 mm Female NPT 3/8” 316 SS SS-10M0-7-6 936E25013 Contact Manufacturer
10 mm Female NPT 1/2” 316 SS SS-10M0-7-8 936E25014 Contact Manufacturer
12 mm Female NPT 1/4” 316 SS SS-12M0-7-4 936E25015 Contact Manufacturer
12 mm Female NPT 3/8” 316 SS SS-12M0-7-6 936E25016 Contact Manufacturer
12 mm Female NPT 1/2” 316 SS SS-12M0-7-8 936E25017 Contact Manufacturer
15 mm Female NPT 1/2” 316 SS SS-15M0-7-8 936E25018 Contact Manufacturer
16 mm Female NPT 1/2” 316 SS SS-16M0-7-8 936E25019 Contact Manufacturer
20 mm Female NPT 1/2” 316 SS SS-20M0-7-8 936E25020 Contact Manufacturer
20 mm Female NPT 3/4” 316 SS SS-20M0-7-12 936E25021 Contact Manufacturer
22 mm Female NPT 3/4” 316 SS SS-22M0-7-12 936E25022 Contact Manufacturer
22 mm Female NPT 1” 316 SS SS-22M0-7-16 936E25023 Contact Manufacturer
25 mm Female NPT 3/4” 316 SS SS-25M0-7-12 936E25024 Contact Manufacturer
25 mm Female NPT 1” 316 SS SS-25M0-7-16 936E25025 Contact Manufacturer

Swagelok Co.

BSPT Tapered Thread Female Connector Tube Fittings

BSPT-Female Connector Tube Fitting-group.png
Female connectors with standard size compression tube socket on one end and a female BSPT, (Tapered Thread) port on the other end. The BSPT conforms to the British Whitworth Standard.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
1/8” Female BSPT 1/8” 316 SS SS-200-7-2RT 937E1101 Contact Manufacturer
1/4” Female BSPT 1/8” 316 SS SS-400-7-2RT 937E1102 Contact Manufacturer
1/4” Female BSPT 1/4” 316 SS SS-400-7-4RT 937E1103 Contact Manufacturer
1/4” Female BSPT 3/8” 316 SS SS-400-7-6RT 937E1104 Contact Manufacturer
1/4” Female BSPT 1/2” 316 SS SS-400-7-8RT 937E1105 Contact Manufacturer
3/8” Female BSPT 1/4” 316 SS SS-600-7-4RT 937E1106 Contact Manufacturer
3/8” Female BSPT 3/8” 316 SS SS-600-7-6RT 937E1107 Contact Manufacturer
3/8” Female BSPT 1/2” 316 SS SS-600-7-8RT 937E1108 Contact Manufacturer
1/2” Female BSPT 1/4” 316 SS SS-810-7-4RT 937E1109 Contact Manufacturer
1/2” Female BSPT 3/8” 316 SS SS-810-7-6RT 937E11010 Contact Manufacturer
1/2” Female BSPT 1/2” 316 SS SS-810-7-8RT 937E11011 Contact Manufacturer

Swagelok Co.

Female BSPT (Tapered Thread) Tube Fitting Connectors, Metric

Tube fitting connectors with a metric size compression tube socket on one end and a female tapered thread port on the other end. The thread complies with the British Whitworth Standard, BSPT.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
3 mm Female BSPT 1/8” 316 SS SS-3M0-7-2RT 938E2601 Contact Manufacturer
6 mm Female BSPT 1/8” 316 SS SS-6M0-7-2RT 938E2602 Contact Manufacturer
6 mm Female BSPT 1/4” 316 SS SS-6M0-7-4RT 938E2603 Contact Manufacturer
6 mm Female BSPT 3/8” 316 SS SS-6M0-7-6RT 938E2604 Contact Manufacturer
6 mm Female BSPT 1/2” 316 SS SS-6M0-7-8RT 938E2605 Contact Manufacturer
8 mm Female BSPT 1/8” 316 SS SS-8M0-7-2RT 938E2606 Contact Manufacturer
8 mm Female BSPT 1/4” 316 SS SS-8M0-7-4RT 938E2607 Contact Manufacturer
8 mm Female BSPT 3/8” 316 SS SS-8M0-7-6RT 938E2608 Contact Manufacturer
8 mm Female BSPT 1/2” 316 SS SS-8M0-7-8RT 938E2609 Contact Manufacturer
10 mm Female BSPT 1/8” 316 SS SS-10M0-7-2RT 938E26010 Contact Manufacturer
10 mm Female BSPT 1/4” 316 SS SS-10M0-7-4RT 938E26011 Contact Manufacturer
10 mm Female BSPT 3/8” 316 SS SS-10M0-7-6RT 938E26012 Contact Manufacturer
10 mm Female BSPT 1/2” 316 SS SS-10M0-7-8RT 938E26013 Contact Manufacturer
12 mm Female BSPT 1/8” 316 SS SS-12M0-7-2RT 938E26014 Contact Manufacturer
12 mm Female BSPT 1/4” 316 SS SS-12M0-7-4RT 938E26015 Contact Manufacturer
12 mm Female BSPT 3/8” 316 SS SS-12M0-7-6RT 938E26016 Contact Manufacturer
12 mm Female BSPT 1/2” 316 SS SS-12M0-7-8RT 938E26017 Contact Manufacturer
12 mm Female BSPT 3/4” 316 SS SS-12M0-7-12RT 938E26018 Contact Manufacturer
15 mm Female BSPT 3/8” 316 SS SS-15M0-7-6RT 938E26019 Contact Manufacturer
15 mm Female BSPT 1/2” 316 SS SS-15M0-7-8RT 938E26020 Contact Manufacturer
20 mm Female BSPT 1/2” 316 SS SS-20M0-7-8RT 938E26021 Contact Manufacturer
20 mm Female BSPT 3/4” 316 SS SS-20M0-7-12RT 938E26022 Contact Manufacturer
22 mm Female BSPT 3/4” 316 SS SS-22M0-7-12RT 938E26023 Contact Manufacturer
22 mm Female BSPT 1” 316 SS SS-22M0-7-16RT 938E26024 Contact Manufacturer
25 mm Female BSPT 3/4” 316 SS SS-25M0-7-12RT 938E26025 Contact Manufacturer
25 mm Female BSPT 1” 316 SS SS-25M0-7-16RT 938E26026 Contact Manufacturer

Swagelok Co.

Female BSPP (Parallel Thread, RT) Tube Fitting Connectors, Metric

Female connectors with metric size compression tube socket on one end and a female BSPP, (Parallel Thread) port on the other end. The BSPP conforms to the British Whitworth Standard.
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
6 mm Female BSPP 1/8” 316 SS SS-6M0-7-2RP 939E401 Contact Manufacturer
6 mm Female BSPP 1/4” 316 SS SS-6M0-7-4RP 939E402 Contact Manufacturer
22 mm Female BSPP 3/4” 316 SS SS-22M0-7-12RP 939E403 Contact Manufacturer
25 mm Female BSPP 1” 316 SS SS-25M0-7-16RP 939E404 Contact Manufacturer

Swagelok Co.

Female BSPP Parallel Thread (RG, Gauge) Tube Fitting Connectors

Female BSPP Parallel Thread (RG, Gauge) Tube Fitting Connector
Tube OD Connection 2 Material Mfg P/N Encole P/N Price
1/8” Female BSPP 1/4” 316 SS SS-200-7-4RG 940E1201 Contact Manufacturer
1/4” Female BSPP 1/8” 316 SS SS-400-7-2RG 940E1202 Contact Manufacturer
1/4” Female BSPP 1/4” 316 SS SS-400-7-4RG 940E1203 Contact Manufacturer
1/4” Female BSPP 3/8” 316 SS SS-400-7-6RG 940E1204 Contact Manufacturer
1/4” Female BSPP 1/2” 316 SS SS-400-7-8RG 940E1205 Contact Manufacturer
5/16” Female BSPP 1/4” 316 SS SS-500-7-4RG 940E1206 Contact Manufacturer
5/16” Female BSPP 1/2” 316 SS SS-500-7-8RG 940E1207 Contact Manufacturer
3/8” Female BSPP 1/4” 316 SS SS-600-7-4RG 940E1208 Contact Manufacturer
3/8” Female BSPP 3/8”
