Check-All Valve
316 Stainless Steel Universal Low Pressure Check Valve, Female NPT
Inlet: 3/4” Female NPT, Housing Material: 316 Stainless, Cracking Pressure: 0.125 psi, Spring Material: 316 SS, Seal Material: Aflas, Spring Encapsulation Option: Standard
Stainless steel check valve in a single-piece body construction. The housing is made from 316 Stainless. Connections are female NPT threads conforming to ASME B1.20.1. Typical applications include in-line check valve to prevent back-flow. This valve can be used a low pressure relief valve or vacuum breaker by choosing low spring settings.
Seal Material:
Spring Encapsulation Option:
Product Drawings and CAD Models Disclaimer
Manufacturing processes and resulting tolerances may result in variations in the specifications provided. Many manufacturers consider their GD&T proprietary and do not provide this to Encole. While we believe the information to be generally correct, it is subject to change without notice and is not guaranteed. Drawings and CAD models are prepared by the Original Manufacturers or CAD expert contibutors or Encole staff.
U3FSSAS.125SS
Check-All Valve
